Description
8 x 21 Walk-In Freezer for Grocery and Supermarket Operations
The Astra AFWF8X21-RM is a nominal 8 x 21 walk-in freezer for planning frozen inventory storage in a grocery store, market or foodservice operation. This listing identifies the remote refrigeration configuration. Use it to compare the enclosure and specified equipment with your storage workflow before ordering. A freezer purchase involves more than fitting a rectangle into a backroom: product temperatures, incoming loads, floor construction and service access all belong in the final project review.
Model details at a glance
| Model | AFWF8X21-RM |
|---|---|
| Nominal footprint | 8 x 21 ft |
| Equipment type | Walk-In Freezer |
| Refrigeration configuration | Remote Refrigeration |
| Listed exterior box dimensions | 8' 2"W x 21' 4"L x 7' 7"H |
| Listed interior box dimensions | 7' 6"W x 20' 8"L x 7' 3"H |
| Listed floor configuration | With Floor |
| Listed shipping weight | 1993 lb |
Size, access and usable space
For AFWF8X21-RM, the catalog lists exterior box dimensions of 8' 2"W x 21' 4"L x 7' 7"H and interior dimensions of 7' 6"W x 20' 8"L x 7' 3"H. Use the exterior measurement to check the proposed location and the interior measurement to develop a storage layout. The nominal 8 x 21 designation is a model-size reference, not a promise of clear floor area or installation clearance. Allow separately for doors, equipment, access to connections and the space required to assemble the panels.
For this larger nominal 8 x 21 footprint, plan receiving, storage and picking together. Identify which inventory needs frequent access and which can sit farther from the entrance. If you are considering multiple shelf runs or a central aisle, test the proposed arrangement against the actual interior measurements. Do not allocate every available inch to shelving; staff movement and access for maintenance remain part of usable planning.
Refrigeration and operating requirements
This SKU is listed with remote refrigeration. Plan the relationship between the condensing equipment, evaporator and enclosure rather than considering the box in isolation. Have the refrigeration contractor review equipment placement, the proposed connection route, electrical requirements and service access. The selected package must suit the actual site and operating load. Do not assume the product price includes field piping, wiring, commissioning or building work; those responsibilities should be specified in the project quote.
Catalog equipment specification
Condensing Unit: Turbo Air Outdoor Condensing Unit, 4.5 HP, Low Temp, Air Cooled, 208-230V/60Hz/1Ph, Copeland Scroll Compressor, R404A, R407C, R448A / R449A
Evaporator: Turbo Air Evaporator, Electric Defrost, EC Motor, Pre-Assembled (R448A, R449A TXV, Solenoid Valve, Digital Temperature Controller), 4 Fans, 15,700 BTU, 208-230V/60Hz/1Ph
The specification above is the current catalog description. Confirm the exact supplied equipment and site suitability on the final quote.
Floor configuration and site preparation
The catalog identifies AFWF8X21-RM as With Floor. Review the floor details with the installer, including the supporting surface, finished entry level and the loads from shelving and handling equipment. A supplied floor does not remove the need to evaluate the building substrate or the freezer installation as a whole. If carts or other wheeled equipment will enter, confirm the threshold arrangement and whether a compatible ramp is required before specifying accessories.
Layouts, alternatives and accessories
This product has 10 linked layout drawings for review. Compare the actual door and panel arrangement with your site plan; a layout image is not permission to interchange every door size, hinge position or panel. Record the chosen drawing with your order so the required arrangement can be checked. Door size and layout selection should be reviewed as separate specification details, and neither should be inferred solely from the product photograph.
Related listings include RR8X21 matching rain roof cover. Shelving, lighting, entry accessories and other additions should be specified for the actual model and use. They are not automatically included because they appear in a photograph or related-product area. For an outdoor installation, confirm the complete outdoor specification; a roof cover alone does not establish that every component is suitable for exposure. Review accessory compatibility and quantities before submitting the order.
Questions to resolve before ordering
Does the listed size include installation clearance?
No. Nominal size is a product designation. Use the exact box dimensions and approved equipment drawings, then account for assembly, door movement, ventilation and service access required by the selected configuration.
What should I send with a quote request?
Include model AFWF8X21-RM, the installation address, room measurements, photos of the site and the products you plan to store. Add the preferred layout, floor requirements and refrigeration selection so the team can review one coordinated specification.
