Astra 10 x 25 Walk-In Cooler & Freezer Combo — CMB10X25

10 x 25 Walk-In Cooler & Freezer Combo for Grocery and Supermarket Operations

The Astra CMB10X25 is a nominal 10 x 25 walk-in cooler and freezer combo for a store that needs refrigerated and frozen storage within a coordinated enclosure layout. This is a box-only listing; refrigeration must be specified separately. The combined format lets you plan two storage functions together while keeping their operating requirements distinct. Start with the amount and type of inventory assigned to each compartment, then review the partition, doors and equipment needed for that layout.

Model details at a glance

Size, access and usable space

For CMB10X25, the catalog lists exterior box dimensions of 9' 10"W x 24' 7"L x 7' 7"H and interior dimensions of 9' 2"W x 23' 11"L x 6' 11"H. Use the exterior measurement to check the proposed location and the interior measurement to develop a storage layout. The nominal 10 x 25 designation is a model-size reference, not a promise of clear floor area or installation clearance. Allow separately for doors, equipment, access to connections and the space required to assemble the panels.

Treat the 10 x 25 footprint as a combined enclosure, not the usable size of either individual compartment. Prepare separate inventory lists for refrigerated and frozen goods. The partition location and door arrangement determine the practical capacity on each side. Do not assume an equal split from the overall dimensions; use the model drawings to confirm how the compartments are actually arranged.

Refrigeration and operating requirements

Refrigeration is not included in this box-only listing. The enclosure must be paired with equipment selected for the intended operating conditions. Share the stored product type, desired temperature, incoming product temperature, loading pattern and expected door use with the refrigeration contractor. These details affect equipment selection; a nominal box size by itself does not establish the required capacity. Keep the enclosure order and refrigeration specification coordinated so openings, equipment placement and installation responsibilities are agreed in advance.

Floor configuration and site preparation

The catalog floor designation for CMB10X25 is With Floor. Verify exactly which compartments that designation covers on the layout drawing, especially at the partition and entrances. Do not assume a combined cooler and freezer has identical floor requirements on both sides. Have the installer review the finished floor level, substrate and any application-specific floor design. This check belongs alongside the compartment and refrigeration review, before the enclosure configuration is finalized.

Layouts, alternatives and accessories

This product has 10 linked layout drawings for review. Compare the actual door and panel arrangement with your site plan; a layout image is not permission to interchange every door size, hinge position or panel. Record the chosen drawing with your order so the required arrangement can be checked. Door size and layout selection should be reviewed as separate specification details, and neither should be inferred solely from the product photograph.

Related listings include RR10X25 matching rain roof cover. Shelving, lighting, entry accessories and other additions should be specified for the actual model and use. They are not automatically included because they appear in a photograph or related-product area. For an outdoor installation, confirm the complete outdoor specification; a roof cover alone does not establish that every component is suitable for exposure. Review accessory compatibility and quantities before submitting the order.

Questions to resolve before ordering

Does the listed size include installation clearance?

No. Nominal size is a product designation. Use the exact box dimensions and approved equipment drawings, then account for assembly, door movement, ventilation and service access required by the selected configuration.

What should I send with a quote request?

Include model CMB10X25, the installation address, room measurements, photos of the site and the products you plan to store. Add the preferred layout, floor requirements and refrigeration selection so the team can review one coordinated specification.

Plan your project with Supermarket World

Supermarket World is the supermarket-focused division of Atlantic Restaurant & Supermarket Equipment, serving the Tri-State region since 1998. From its Kearny, New Jersey base, the team supports equipment planning for independent markets, grocery stores and larger projects along the New York–Washington, DC corridor. Request a project quote to confirm the equipment and service scope, or purchase the listed configuration when its specifications match your approved plan.

Coordinate delivery before installation

Before arranging delivery, confirm the receiving location, unloading arrangements and the route to the installation area. Share doorway measurements, access restrictions and any appointment requirements with the team. Keep the final model, selected equipment and drawings together so the receiving and installation teams work from the same information. Discuss any service or installation charges separately rather than assuming they are part of the product listing. At receiving, compare the delivered items with the packing list and record any visible damage or missing components before scheduling assembly.
